SSI-Schäfer Frame P95 - 7400 x 1050 mm - compleet
SSI Schäfer P95 frame 7400x1050 complete
Complete galvanized SSI Schäfer frame type P95 for pallet racking repair/expansion. Includes 2 uprights 90 mm, bracing, base plates and fasteners; height 7400 mm, frame depth 1050 mm.
Specifications
- Brand/type: SSI Schäfer P95
- Dimensions: 7400 x 1050 mm
- 2 uprights 90 mm
- Galvanized
- Incl. bracing, base plates, fasteners
Complete frame as a stable foundation for your pallet racking setup
This complete SSI Schäfer frame of type P95 forms the supporting side of your pallet racking and is designed for safe, secure construction of storage bays. The galvanized finish provides corrosion protection and is therefore suitable for intensive warehouse use. With a height of 7400 mm and a frame depth of 1050 mm, this frame provides a solid foundation for high storage installations.
Application in the warehouse
A frame determines the stability of the storage bay and, together with the beams, carries the load of pallets. This frame is supplied as a complete unit with two 90 mm wide P95 uprights, base plates, horizontal and diagonal bracing and the associated fastening material, so you can build or replace it in a targeted manner without having to assemble loose parts.
Practical for replacement or expansion
Ideal for B2B projects where speed and continuity matter: replacing damage, restoring a racking row or expanding existing SSI Schäfer P95 installations. The complete assembly makes it a practical choice for maintenance teams and assembly partners looking for clarity and reliable components.
Possible beam configurations and pallet heights
For a frame height of 7400 mm, the following beam configurations are possible (bay height and maximum pallet height per level, from bottom to top):
3 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 2450 | 2300 | 2200 |
| 1st beam | 4900 | 2300 | 2200 |
| 2nd beam | 7300 | 2250 | 2150 |
4 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1850 | 1700 | 1600 |
| 1st beam | 3700 | 1700 | 1600 |
| 2nd beam | 5500 | 1650 | 1550 |
| 3rd beam | 7300 | 1650 | 1550 |
5 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1500 | 1350 | 1250 |
| 1st beam | 2950 | 1300 | 1200 |
| 2nd beam | 4400 | 1300 | 1200 |
| 3rd beam | 5850 | 1300 | 1200 |
| 4th beam | 7300 | 1300 | 1200 |
| SKU | RV1-975-0740-105 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | SSI Schäfer |
| Artikelnummer Fabrikant | RV1-975-0740-105 |
| Product Group | Complete Frames |
| Frame Type | P95 |
| Condition | New |
| Length (mm) | 7400 |
| Width (mm) | 90 |
| Depth (mm) | 1050 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
