SSI-Schäfer Frame P95 - 2500 x 1050 mm - compleet
Complete SSI Schäfer P95 frame 2500x1050
Galvanized complete frame for pallet racking, ideal for replacement/expansion of SSI Schäfer Type P95. Includes uprights, bracing and fastening material.
SSI Schäfer Frame P95 Specifications
- Type: P95, 2 uprights 90 mm
- Height: 2500 mm
- Frame depth: 1050 mm
- Finish: galvanized
- Includes: base plates, horizontal/diagonal bracing, fastening material
Complete frame as a solid foundation for a safe pallet racking system
This complete SSI Schäfer frame from the P95 series forms the supporting side wall of a pallet racking system and is designed for stable, durable installation in the warehouse. The frame is supplied as a complete set with two P95 uprights (90 mm wide), base plates, horizontal and diagonal bracing and the corresponding fastening material. The galvanized finish helps provide protection against corrosion in demanding work environments.
Warehouse application
Frames determine the height and depth of the racking and together with the beams carry the weight of pallets and goods. With an upright height of 2500 mm and frame depth of 1050 mm, this frame is suitable for standard pallet positions where a solid load-bearing structure is required.
Practical for replacement or expansion
Ideal for B2B projects where fast and consistent construction is required: replacement of damaged uprights, expansion of existing rows or construction of a new racking section within SSI Schäfer P95. The complete delivery saves installation time and prevents missing parts on site.
Possible beam configurations and pallet heights
For a frame height of 2500 mm, the following beam configurations are possible (bay height and maximum pallet height per level, from bottom to top):
2 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1200 | 1050 | 950 |
| 1st beam | 2400 | 1050 | 950 |
3 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 800 | 650 | 550 |
| 1st beam | 1600 | 650 | 550 |
| 2nd beam | 2400 | 650 | 550 |
4 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 600 | 450 | 350 |
| 1st beam | 1200 | 450 | 350 |
| 2nd beam | 1800 | 450 | 350 |
| 3rd beam | 2400 | 450 | 350 |
5 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 500 | 350 | 250 |
| 1st beam | 1000 | 350 | 250 |
| 2nd beam | 1500 | 350 | 250 |
| 3rd beam | 1950 | 300 | 200 |
| 4th beam | 2400 | 300 | 200 |
| SKU | RV1-975-0250-105 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | SSI Schäfer |
| Artikelnummer Fabrikant | RV1-975-0250-105 |
| Product Group | Complete Frames |
| Frame Type | P95 |
| Condition | New |
| Length (mm) | 2500 |
| Width (mm) | 90 |
| Depth (mm) | 1050 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
