SSI-Schäfer Frame P95 - 3600 x 1050 mm - compleet
SSI Schäfer P95 Frame Complete 3600x1050 mm
Complete galvanised frame for SSI Schäfer pallet racking type P95, ideal for replacement or expansion. New, with 2 uprights (90 mm), bracing, base plates and fastening material; height 3600 mm, frame depth 1050 mm.
Specifications
- Brand/Type: SSI Schäfer P95
- Condition: new, galvanised
- Dimensions: 3600 x 1050 mm
- 2 uprights 90 mm + bracing
- Incl. base plates & fastening material
SSI-Schäfer Frame P95 - 4100 x 1050 mm - compleet
Previous
Complete frame as a stable base for your pallet racking system
This complete SSI Schäfer frame of type P95 forms the supporting side panel of a pallet racking system and is designed for safe, secure assembly of your warehouse shelving. With two P95 uprights of 90 mm width and a height of 3600 mm, you have a solid foundation for multi-level storage. The galvanised finish helps prevent corrosion and is suitable for intensive use in a professional storage environment.
Warehouse Application
A frame determines the stability, depth and alignment of your racking row. This unit has a frame depth of 1050 mm and is supplied including base plates, horizontal and diagonal bracing and the associated fastening material, so you can assemble directly or replace a damaged component without searching for loose parts.
Practical for Replacement or Expansion
Ideal for B2B projects where you want to expand or restore SSI Schäfer P95 racking material. The complete composition reduces assembly time and minimizes warehouse downtime, while maintaining consistent construction within your existing P95 system.
Possible beam configurations and pallet heights
For a frame height of 3600 mm, the following beam configurations are possible (bay height and maximum pallet height per level, from bottom to top):
2 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1750 | 1600 | 1500 |
| 1st beam | 3500 | 1600 | 1500 |
3 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1200 | 1050 | 950 |
| 1st beam | 2350 | 1000 | 900 |
| 2nd beam | 3500 | 1000 | 900 |
4 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 900 | 750 | 650 |
| 1st beam | 1800 | 750 | 650 |
| 2nd beam | 2650 | 700 | 600 |
| 3rd beam | 3500 | 700 | 600 |
5 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 700 | 550 | 450 |
| 1st beam | 1400 | 550 | 450 |
| 2nd beam | 2100 | 550 | 450 |
| 3rd beam | 2800 | 550 | 450 |
| 4th beam | 3500 | 550 | 450 |
| SKU | RV1-975-0360-105 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | SSI Schäfer |
| Artikelnummer Fabrikant | RV1-975-0360-105 |
| Product Group | Complete Frames |
| Frame Type | P95 |
| Condition | New |
| Length (mm) | 3600 |
| Width (mm) | 90 |
| Depth (mm) | 1050 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
