SSI-Schäfer Frame P95 - 6300 x 1050 mm - compleet
Complete SSI Schäfer P95 frame 6300x1050 mm (galvanized)
Complete SSI-Schäfer frame type P95 for pallet racking, ideal as replacement frame or extension. Galvanized finish for durable warehouse shelving.
Specifications SSI Schäfer frame P95
- 6300 x 1050 mm frame depth
- 2 uprights P95, 90 mm wide
- Galvanized, incl. base plates
- Horizontal/diagonal bracing + fastening material
SSI-Schäfer Frame P95 - 6900 x 1050 mm - compleet
Previous
Complete frame as sturdy foundation for your pallet racking setup
This complete SSI Schäfer frame (type P95) forms the load-bearing structure of your pallet racking and is designed for stable, safe assembly of racking rows in warehouse and distribution environments. The frame is supplied as a complete assembly with two P95 uprights (90 mm wide), bracing and base plates, enabling you to assemble quickly and give the structure the proper rigidity. The galvanized finish also provides protection during long-term use in intensive working environments.
Application in the warehouse
A frame is positioned as an upright section to which beams are attached and determines, among other things, the frame depth of your racking. With a height of 6300 mm and a frame depth of 1050 mm, this frame is suitable for setups where height utilization and fixed depth are essential for pallet storage and aisle logistics.
Practical for replacement or expansion
Ideal for B2B customers who want to restore or expand an existing SSI Schäfer P95 setup with a complete pallet racking component. Thanks to the included horizontal and diagonal bracing and matching fastening material, you minimize assembly time and avoid mismatches during replacement.
Possible beam configurations and pallet heights
For a frame height of 6300 mm, the following beam configurations are possible (bay height and maximum pallet height per level, from bottom to top):
3 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 2100 | 1950 | 1850 |
| 1st beam | 4150 | 1900 | 1800 |
| 2nd beam | 6200 | 1900 | 1800 |
4 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1550 | 1400 | 1300 |
| 1st beam | 3100 | 1400 | 1300 |
| 2nd beam | 4650 | 1400 | 1300 |
| 3rd beam | 6200 | 1400 | 1300 |
5 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1250 | 1100 | 1000 |
| 1st beam | 2500 | 1100 | 1000 |
| 2nd beam | 3750 | 1100 | 1000 |
| 3rd beam | 5000 | 1100 | 1000 |
| 4th beam | 6200 | 1050 | 950 |
| SKU | RV1-975-0630-105 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | SSI Schäfer |
| Artikelnummer Fabrikant | RV1-975-0630-105 |
| Product Group | Complete Frames |
| Frame Type | P95 |
| Condition | New |
| Length (mm) | 6300 |
| Width (mm) | 90 |
| Depth (mm) | 1050 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
