SSI-Schäfer Frame P95 - 6900 x 1050 mm - compleet
SSI Schäfer P95 Complete Frame 6900x1050
Galvanized complete SSI Schäfer frame P95 for pallet racking; ideal for expansion or replacement. Includes 2 uprights 90 mm, bracing and mounting materials.
Specifications
- Brand/Type: SSI Schäfer P95
- Dimensions: 6900x1050 mm
- 2 uprights 90 mm wide
- Galvanized, incl. base plates
- Horiz./diag. bracing + fastening materials
SSI-Schäfer Frame P95 - 2500 x 1050 mm - compleet
Previous
Complete frame as stable foundation for safe pallet racking
This complete SSI Schäfer frame (type P95) forms the vertical load-bearing structure of your pallet racking and is designed for reliable installation or reconfiguration of warehouse racking systems. The frame consists of two P95 uprights 90 mm wide with a height of 6900 mm, executed in galvanized steel for durable finishing. With a frame depth of 1050 mm, it is suitable as a sturdy side construction on which beams and storage levels are built.
Application in the warehouse
A frame determines the stability and dimensions of the storage bay. The included horizontal and diagonal bracing provides the necessary rigidity, while base plates transfer the load neatly to the floor. Ideal for setting up new storage rows or restoring a damaged bay.
Practical for replacement or expansion
Because this is a complete frame including fastening materials, you can proceed quickly with replacement or expansion without having to assemble loose components. An efficient choice for maintenance departments, warehouse installers and companies using SSI Schäfer P95 racking materials.
Possible beam configurations and pallet heights
For a frame height of 6900 mm, the following beam configurations are possible (bay height and maximum pallet height per level, from bottom to top):
3 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 2300 | 2150 | 2050 |
| 1st beam | 4550 | 2100 | 2000 |
| 2nd beam | 6800 | 2100 | 2000 |
4 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1700 | 1550 | 1450 |
| 1st beam | 3400 | 1550 | 1450 |
| 2nd beam | 5100 | 1550 | 1450 |
| 3rd beam | 6800 | 1550 | 1450 |
5 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1400 | 1250 | 1150 |
| 1st beam | 2750 | 1200 | 1100 |
| 2nd beam | 4100 | 1200 | 1100 |
| 3rd beam | 5450 | 1200 | 1100 |
| 4th beam | 6800 | 1200 | 1100 |
| SKU | RV1-975-0690-105 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | SSI Schäfer |
| Artikelnummer Fabrikant | RV1-975-0690-105 |
| Product Group | Complete Frames |
| Frame Type | P95 |
| Condition | New |
| Length (mm) | 6900 |
| Width (mm) | 90 |
| Depth (mm) | 1050 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
