SSI-Schäfer Frame P95 - 5800 x 1050 mm - compleet
SSI Schäfer P95 complete frame 5800x1050 galvanized
Complete SSI-Schäfer frame type P95 for pallet racking; ideal as replacement or expansion. Galvanized, complete with uprights, bracing, base plates and fastening materials (frame 5800x1050mm).
Specifications
- Type: SSI Schäfer P95
- Dimensions: 5800 x 1050 mm
- 2 uprights 90 mm wide
- Galvanized; incl. bracing, base plates, fastening
SSI-Schäfer Frame P95 - 6300 x 1050 mm - compleet
Previous
Robust frame as stable basis for secure pallet racking
This complete SSI Schäfer frame is designed as the load-bearing side of a pallet racking system and forms the foundation for a stable and reliable storage solution. It features a galvanized finish for durable warehouse use, with uprights of type P95 (90 mm wide). With a height of 5800 mm and frame depth 1050 mm, the frame is suitable for building higher racking bays where stability and dimensional accuracy are essential.
Application in the warehouse
A frame supports the beams and determines the depth of the racking. Horizontal and diagonal bracing reinforces the structure, contributing to safe pallet storage and neat alignment of racking rows. Base plates ensure solid floor connection.
Practical for replacement or expansion
Ideal for businesses wanting to restore or expand an existing SSI Schäfer P95 installation with a complete frame including associated fastening materials, enabling efficient assembly and expansion.
Possible beam configurations and pallet heights
For a frame height of 5800 mm, the following beam configurations are possible (bay height and maximum pallet height per level, from bottom to top):
3 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1900 | 1750 | 1650 |
| 1st beam | 3800 | 1750 | 1650 |
| 2nd beam | 5700 | 1750 | 1650 |
4 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1450 | 1300 | 1200 |
| 1st beam | 2900 | 1300 | 1200 |
| 2nd beam | 4300 | 1250 | 1150 |
| 3rd beam | 5700 | 1250 | 1150 |
5 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1150 | 1000 | 900 |
| 1st beam | 2300 | 1000 | 900 |
| 2nd beam | 3450 | 1000 | 900 |
| 3rd beam | 4600 | 1000 | 900 |
| 4th beam | 5700 | 950 | 850 |
| SKU | RV1-975-0580-105 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | SSI Schäfer |
| Artikelnummer Fabrikant | RV1-975-0580-105 |
| Product Group | Complete Frames |
| Frame Type | P95 |
| Condition | New |
| Length (mm) | 5800 |
| Width (mm) | 90 |
| Depth (mm) | 1050 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
