SSI-Schäfer Frame P95 - 4700 x 1050 mm - compleet
SSI Schäfer P95 complete frame 4700x1050 mm
New galvanized pallet racking frame with 2 P95 uprights (90 mm), bracing, base plates and fastening material; ideal for assembly or replacement of SSI Schäfer warehouse racking systems.
Specifications
- Brand/type: SSI Schäfer P95
- Dimensions: 4700 mm high, 1050 mm deep
- 2 uprights 90 mm + bracing
- Galvanized, incl. base plates + fastening
SSI-Schäfer Frame P95 - 5200 x 1050 mm - compleet
Previous
Complete frame as stable base for your pallet racking
This complete SSI Schäfer frame from the P95 series forms the load-bearing side structure of your pallet racking and ensures reliable assembly of racking sections. With two P95 uprights (90 mm wide) in galvanized finish, the frame is suitable for warehouse environments where durability and neat finish are important. The frame depth of 1050 mm and upright height of 4700 mm make it a practical choice for higher installations with sufficient installation space.
Application in the warehouse
A frame is placed on the floor and serves as a connection point for beams, allowing you to build pallet positions in rows or aisles. The included horizontal and diagonal bracing contribute to stability, while base plates ensure a solid installation on the floor.
Practical for replacement or expansion
Ideal when you want to replace a damaged frame or expand your existing SSI Schäfer P95 system with a complete, ready-to-use frame unit including associated fastening material.
Possible beam configurations and pallet heights
For a frame height of 4700 mm, the following beam configurations are possible (bay height and maximum pallet height per level, from bottom to top):
2 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 2300 | 2150 | 2050 |
| 1st beam | 4600 | 2150 | 2050 |
3 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1550 | 1400 | 1300 |
| 1st beam | 3100 | 1400 | 1300 |
| 2nd beam | 4600 | 1350 | 1250 |
4 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1150 | 1000 | 900 |
| 1st beam | 2300 | 1000 | 900 |
| 2nd beam | 3450 | 1000 | 900 |
| 3rd beam | 4600 | 1000 | 900 |
5 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 950 | 800 | 700 |
| 1st beam | 1900 | 800 | 700 |
| 2nd beam | 2800 | 750 | 650 |
| 3rd beam | 3700 | 750 | 650 |
| 4th beam | 4600 | 750 | 650 |
| SKU | RV1-975-0470-105 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | SSI Schäfer |
| Artikelnummer Fabrikant | RV1-975-0470-105 |
| Product Group | Complete Frames |
| Frame Type | P95 |
| Condition | New |
| Length (mm) | 4700 |
| Width (mm) | 90 |
| Depth (mm) | 1050 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
