SSI-Schäfer Frame P95 - 3000 x 1050 mm - compleet
SSI Schäfer P95 frame 3000x1050 complete
Complete galvanized SSI-Schäfer frame type P95 for pallet racking, ideal for replacement or expansion. New.
Specifications
- 3000x1050 mm
- 2 uprights P95 (90 mm)
- Base plates + fastening
- Horizontal/diagonal bracing
SSI-Schäfer Frame P95 - 3600 x 1050 mm - compleet
Previous
Complete frame as a solid foundation for stable pallet racking
This complete SSI Schäfer frame (type P95) forms the load-bearing structure of your pallet racking and is designed as a reliable foundation for beams and compartment layout. With an upright height of 3000 mm and a frame depth of 1050 mm, the frame is suitable for standard pallet positions where stability and dimensional accuracy are essential. The galvanized finish helps with long-term use in warehouse environments.
Warehouse application
The frame is constructed from two P95 uprights 90 mm wide and is equipped with horizontal and diagonal bracing for the required rigidity. With the included base plates and associated fastening material, the frame is ready for immediate use within an SSI Schäfer P95 racking setup.
Practical for replacement or expansion
Ideal when you want to replace a damaged frame or expand an existing racking row with identical depth. A complete frame prevents component mismatch and accelerates on-site assembly, ensuring your storage capacity is operational again quickly.
Possible beam configurations and pallet heights
For a frame height of 3000 mm, the following beam configurations are possible (bay height and maximum pallet height per level, from bottom to top):
2 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1450 | 1300 | 1200 |
| 1st beam | 2900 | 1300 | 1200 |
3 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1000 | 850 | 750 |
| 1st beam | 1950 | 800 | 700 |
| 2nd beam | 2900 | 800 | 700 |
4 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 750 | 600 | 500 |
| 1st beam | 1500 | 600 | 500 |
| 2nd beam | 2200 | 550 | 450 |
| 3rd beam | 2900 | 550 | 450 |
5 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 600 | 450 | 350 |
| 1st beam | 1200 | 450 | 350 |
| 2nd beam | 1800 | 450 | 350 |
| 3rd beam | 2350 | 400 | 300 |
| 4th beam | 2900 | 400 | 300 |
| SKU | RV1-975-0300-105 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | SSI Schäfer |
| Artikelnummer Fabrikant | RV1-975-0300-105 |
| Product Group | Complete Frames |
| Frame Type | P95 |
| Condition | New |
| Length (mm) | 3000 |
| Width (mm) | 90 |
| Depth (mm) | 1050 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
