SSI-Schäfer Frame P93 - 7400 x 1050 mm - compleet
SSI Schäfer P93 complete frame 7400x1050 mm
Complete SSI-Schäfer frame type P93 for pallet racking, galvanized and ideal for replacement/expansion in warehouse systems. Includes uprights, bracing, base plates and fastening materials.
Specifications
- Type: P93, 2 uprights 90 mm
- Height: 7400 mm
- Frame depth: 1050 mm
- Galvanized; incl. bracing, base plates & fastening
Complete frame as stable foundation for your pallet racking
This complete SSI Schäfer frame is designed as the load-bearing side component of a pallet racking system and forms the foundation for a safe, rigid structure of your warehouse shelving. It is a galvanized version with type P93 uprights of 90 mm width, designed for a frame depth of 1050 mm and an upright length of 7400 mm, including base plates.
Application in the warehouse
A frame determines the height and depth of the rack bay and carries, together with beams, the load of pallets and goods. Thanks to the horizontal and diagonal bracing, the structure remains stable, even with intensive use in logistics environments where reliability and dimensional accuracy are essential.
Practical for replacement or expansion
Supplied as a complete unit with associated fastening materials, this frame is practical for replacing damaged parts or expanding an existing SSI Schäfer P93 system, without having to assemble loose components. The galvanized finish supports durable use in various warehouse conditions.
Possible beam configurations and pallet heights
For a frame height of 7400 mm, the following beam configurations are possible (bay height and maximum pallet height per level, from bottom to top):
3 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 2450 | 2300 | 2200 |
| 1st beam | 4900 | 2300 | 2200 |
| 2nd beam | 7300 | 2250 | 2150 |
4 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1850 | 1700 | 1600 |
| 1st beam | 3700 | 1700 | 1600 |
| 2nd beam | 5500 | 1650 | 1550 |
| 3rd beam | 7300 | 1650 | 1550 |
5 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1500 | 1350 | 1250 |
| 1st beam | 2950 | 1300 | 1200 |
| 2nd beam | 4400 | 1300 | 1200 |
| 3rd beam | 5850 | 1300 | 1200 |
| 4th beam | 7300 | 1300 | 1200 |
| SKU | RV1-973-0740-105 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | SSI Schäfer |
| Artikelnummer Fabrikant | RV1-973-0740-105 |
| Product Group | Complete Frames |
| Frame Type | P93 |
| Condition | New |
| Length (mm) | 7400 |
| Width (mm) | 90 |
| Depth (mm) | 1050 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
