SSI-Schäfer Frame P93 - 3000 x 1050 mm - compleet
Complete SSI Schäfer P93 frame 3000x1050 mm
New galvanised complete SSI-Schäfer frame type P93 for pallet racking; ideal for expansion, replacement or repair. With 2 uprights 3000 mm (90 mm) and frame depth 1050 mm for robust warehouse storage.
Specifications SSI Schäfer frame P93
- Type: P93 complete frame
- Brand: SSI Schäfer
- Height: 3000 mm
- Depth: 1050 mm
- 2 uprights: 90 mm wide
- Galvanised, incl. base plates, bracing & fastening material
SSI-Schäfer Frame P93 - 3600 x 1050 mm - compleet
Previous
Complete frame as stable foundation for your pallet racking
This complete SSI Schäfer frame from the P93 series forms the supporting side of a pallet racking system and is designed for safe, tight assembly of your racking row. With two uprights of 3000 mm (90 mm wide), galvanised finish and a frame depth of 1050 mm, the frame is suitable for robust warehouse applications where reliability and dimensional accuracy are important.
Application in the warehouse
Frames determine the stability of the racking bay and support the beams and load. This frame is supplied including base plates, horizontal and diagonal bracing and associated fastening material, allowing you to install or replace a complete upright section within an SSI Schäfer P93 pallet racking system.
Practical for replacement or expansion
Ideal for maintenance, damage repair or expansion of existing racking: you receive a complete frame assembly in one shipment, which limits assembly time and supports continuity in the warehouse. The galvanised finish also helps keep the structure clean and durable in daily logistics environments.
Possible beam configurations and pallet heights
For a frame height of 3000 mm, the following beam configurations are possible (bay height and maximum pallet height per level, from bottom to top):
2 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1450 | 1300 | 1200 |
| 1st beam | 2900 | 1300 | 1200 |
3 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1000 | 850 | 750 |
| 1st beam | 1950 | 800 | 700 |
| 2nd beam | 2900 | 800 | 700 |
4 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 750 | 600 | 500 |
| 1st beam | 1500 | 600 | 500 |
| 2nd beam | 2200 | 550 | 450 |
| 3rd beam | 2900 | 550 | 450 |
5 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 600 | 450 | 350 |
| 1st beam | 1200 | 450 | 350 |
| 2nd beam | 1800 | 450 | 350 |
| 3rd beam | 2350 | 400 | 300 |
| 4th beam | 2900 | 400 | 300 |
| SKU | RV1-973-0300-105 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | SSI Schäfer |
| Artikelnummer Fabrikant | RV1-973-0300-105 |
| Product Group | Complete Frames |
| Frame Type | P93 |
| Condition | New |
| Length (mm) | 3000 |
| Width (mm) | 90 |
| Depth (mm) | 1050 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
