SSI-Schäfer Frame P93 - 6900 x 1050 mm - compleet
SSI Schäfer P93 complete frame 6900x1050 mm galvanized
Complete SSI Schäfer frame type P93 (used) for pallet racking; ideal as a replacement part or extension. With 2 uprights 90 mm, frame depth 1050 mm and height 6900 mm.
Specifications
- Brand/type: SSI Schäfer P93
- Dimensions: 6900 x 1050 mm
- 2 uprights 90 mm wide
- Galvanized; incl. base plates, bracing and fastening material
SSI-Schäfer Frame P93 - 2500 x 1050 mm - compleet
Previous
Complete pallet racking frame for stable and durable racking construction
This complete SSI Schäfer frame from the P93 series forms the load-bearing side of a pallet racking system and is designed for reliable assembly of warehouse racking. The frame consists of two P93 uprights 90 mm wide with a length of 6900 mm and is galvanized for extra protection in intensive logistics environments. With a frame depth of 1050 mm, this frame is suitable for applications where a robust and solid base is essential.
Application in the warehouse
Frames transfer the load via the beams to the floor and determine the stability and depth of the racking bay. Thanks to base plates and a complete set of horizontal and diagonal bracing, a rigid structure is created that minimizes movement and twisting, important for daily use with pallet jacks, reach trucks or forklifts.
Practical for replacement or extension
Supplied as a complete frame including associated fastening material, allowing you to quickly replace after damage or extend an existing SSI Schäfer P93 system without having to assemble loose parts.
Possible beam configurations and pallet heights
For a frame height of 6900 mm, the following beam configurations are possible (bay height and maximum pallet height per level, from bottom to top):
3 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 2300 | 2150 | 2050 |
| 1st beam | 4550 | 2100 | 2000 |
| 2nd beam | 6800 | 2100 | 2000 |
4 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1700 | 1550 | 1450 |
| 1st beam | 3400 | 1550 | 1450 |
| 2nd beam | 5100 | 1550 | 1450 |
| 3rd beam | 6800 | 1550 | 1450 |
5 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1400 | 1250 | 1150 |
| 1st beam | 2750 | 1200 | 1100 |
| 2nd beam | 4100 | 1200 | 1100 |
| 3rd beam | 5450 | 1200 | 1100 |
| 4th beam | 6800 | 1200 | 1100 |
| SKU | RV1-973-0690-105 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | SSI Schäfer |
| Artikelnummer Fabrikant | RV1-973-0690-105 |
| Product Group | Complete Frames |
| Frame Type | P93 |
| Condition | New |
| Length (mm) | 6900 |
| Width (mm) | 90 |
| Depth (mm) | 1050 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
