SSI-Schäfer Frame P93 - 6300 x 1050 mm - compleet
SSI Schäfer P93 complete frame 6300x1050 mm
New galvanized SSI-Schäfer P93 frame for pallet racking; ideal as replacement part or extension. Complete upright construction with bracing and fasteners, suitable for warehouse storage systems with frame depth 1050 mm.
Specifications
- Type: SSI Schäfer P93
- Dimensions: 6300x1050 mm
- 2 uprights 90 mm
- Galvanized, complete incl. base plates, bracing & fasteners
SSI-Schäfer Frame P93 - 6900 x 1050 mm - compleet
Previous
Galvanized pallet racking frame for stable, high-level storage bays
This complete SSI Schäfer frame from the P93 system forms the load-bearing side of your pallet racking and is designed for safe, plumb construction of warehouse storage systems. Thanks to the galvanized finish, the frame withstands daily loading and is suitable for long-term use in various storage environments. The frame is supplied complete with two P93 uprights 90 mm wide, bracing, base plates and the corresponding fastening material.
Application in the warehouse
A frame determines the height and depth of a storage section and, together with the beams, ensures a stable structure. With an upright height of 6300 mm and a frame depth of 1050 mm, this frame is suitable for higher racking installations where space-efficient pallet storage is the priority.
Practical for replacement or extension
Ideal for companies looking to expand an SSI Schäfer P93 installation or replace a damaged frame without having to source individual parts. The complete assembly accelerates installation and helps minimize warehouse downtime.
Possible beam configurations and pallet heights
For a frame height of 6300 mm, the following beam configurations are possible (bay height and maximum pallet height per level, from bottom to top):
3 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 2100 | 1950 | 1850 |
| 1st beam | 4150 | 1900 | 1800 |
| 2nd beam | 6200 | 1900 | 1800 |
4 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1550 | 1400 | 1300 |
| 1st beam | 3100 | 1400 | 1300 |
| 2nd beam | 4650 | 1400 | 1300 |
| 3rd beam | 6200 | 1400 | 1300 |
5 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1250 | 1100 | 1000 |
| 1st beam | 2500 | 1100 | 1000 |
| 2nd beam | 3750 | 1100 | 1000 |
| 3rd beam | 5000 | 1100 | 1000 |
| 4th beam | 6200 | 1050 | 950 |
| SKU | RV1-973-0630-105 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | SSI Schäfer |
| Artikelnummer Fabrikant | RV1-973-0630-105 |
| Product Group | Complete Frames |
| Frame Type | P93 |
| Condition | New |
| Length (mm) | 6300 |
| Width (mm) | 90 |
| Depth (mm) | 1050 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
