Dexion P90 Beam 3600x160x50x2.0 - C35 - galvanized
Dexion P90 galvanized beam 3600 mm (new)
New Dexion P90 2C beam for pallet racking, galvanized and ideal as a replacement beam. Length 3600 mm with C35 connector for frames up to 2.5 mm, incl. 2 locking pins.
Specifications
- Brand/series: Dexion P90
- Type: 2C beam, galvanized
- Dim.: 3600 x 160 x 50 mm (LxHxD), 2.0 mm
- Connector: C35 (frame up to 2.5 mm)
- Includes: 2 locking pins
- Suitable for: four euro pallets (800 x 1200 mm) or three block pallets (1000 x 1200 mm) side by side
Dexion P90 Beam 3600x100x50x1.5 - C45 - galvanized
Previous
Galvanized beam for stable and safe pallet racking bays
This new Dexion beam is designed for building sturdy bays within a pallet racking system and is supplied including 2 locking pins for reliable locking. The galvanized finish is practical in demanding warehouse environments where durability and a neat finish are important. With a length of 3600 mm and a profile of 160 x 50 mm, this beam provides a solid base for shelf levels within the Dexion P90 series.
Application in the warehouse
You use this beam to connect two frames, creating a storage level for palletized goods. The C35 connector type is intended for frames with a material thickness up to and including 2.5 mm, so the connection is correct and stable within the P90 setup. The material thickness of 2.0 mm contributes to a robust design for daily use.
Practical for replacement or expansion
Suitable for companies looking to expand a Dexion P90 setup or replace a damaged beam with a matching component. Thanks to the clear Dexion coding on the beam, identification and maintenance within your racking management is easier.
Suitable for pallets
With a beam length of 3600 mm, this beam pair provides room for four euro pallets (800 x 1200 mm) or three block pallets (1000 x 1200 mm) side by side. According to the NEN-EN 15512 standard, a minimum clearance of 75 mm between pallets is maintained, which equates to an average maximum pallet width of 806.2 mm. This length is often chosen for racking bays with a fixed, uniform pallet layout.
| SKU | 100190039 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | Dexion |
| Artikelnummer Fabrikant | 100190039 |
| Product Group | Beam |
| Beam Type | P90 |
| Condition | New |
| Beam Length | 3600 |
| Height (mm) | 160 |
| Depth (mm) | 50 |
| Thickness (mm) | 2 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
