Dexion P90 Beam 3600x140x50x1.5 - C45 - galvanized
Dexion P90 galvanized beam 3600 mm (C45)
New Dexion P90 2C beam for pallet racking; ideal as a replacement/extension. Galvanized, 3600x140x50 mm, 1.5 mm, incl. 2 locking pins, C45 connector.
Specifications
- Brand/series: Dexion P90
- Type: 2C beam, galvanized
- Length: 3600 mm
- Dim.: 140x50 mm, 1.5 mm
- Connector: C45 (frames ≥2.8 mm)
- Incl.: 2 locking pins
- Suitable for: four euro pallets (800 x 1200 mm) or three block pallets (1000 x 1200 mm) side by side
Dexion P90 Beam 3600x150x50x1.8 - C45 - galvanized
Previous
Galvanized beam for stable and safe pallet racking bays
This Dexion beam is a new, galvanized 2C beam for pallet racking, supplied including 2 locking pins. With a length of 3600 mm and a profile of 140 x 50 mm, this beam provides a robust base for building up or repairing a racking bay, with the galvanization helping against corrosion in demanding warehouse environments.
Application in the warehouse
The beam forms the horizontal connection between two frames and determines the bay width and load-bearing structure of the level. This model is suitable for the Dexion P90 product series and features connector type C45, intended for frames with a material thickness from 2.8 mm. The locking pins provide extra securing and reliable operation.
Practical for replacement or extension
Ideal for technical service, warehouse management, or racking installers who want to quickly replace a damaged beam or add extra levels without compromising on fit within the P90 system. The clear Dexion coding on the beam supports quick identification during maintenance and stock management.
Suitable for pallets
With a beam length of 3600 mm, this beam pair accommodates four euro pallets (800 x 1200 mm) or three block pallets (1000 x 1200 mm) side by side. In accordance with NEN-EN 15512, a minimum clearance of 75 mm between pallets is maintained, corresponding to an average maximum pallet width of 806.2 mm. This length is often chosen for racking bays with a fixed, uniform pallet layout.
| SKU | 100182089 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | Dexion |
| Artikelnummer Fabrikant | 100182089 |
| Product Group | Beam |
| Beam Type | P90 |
| Condition | New |
| Beam Length | 3600 |
| Height (mm) | 140 |
| Depth (mm) | 50 |
| Thickness (mm) | 1.5 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
