Dexion P90 Beam 3900x160x50x2.0 - C35 - galvanized
Dexion P90 galvanized beam 3900 mm
New Dexion P90 2C beam for pallet racking, galvanized and ideal as a replacement part. Length 3900 mm, 160x50x2.0 mm, C35 connector; supplied with 2 locking pins.
Specifications
- Type: Dexion P90 2C beam (galvanized)
- Length: 3900 mm
- Size: 160x50 mm, 2.0 mm
- Connector: C35 (frame up to 2.5 mm)
- Incl.: 2 locking pins
- Suitable for: four euro pallets (800 x 1200 mm) or three block pallets (1000 x 1200 mm) side by side
Dexion P90 Beam 3900x140x50x1.5 - C45 - galvanized
Previous
Galvanized beam for stable and safe pallet racking bays
This Dexion beam is designed for building strong beam pairs within a pallet racking system and forms the load-bearing base for pallets and carriers. The version is galvanized and is supplied with 2 locking pins, so the connection can be secured against unintentional release. With a length of 3900 mm and a height of 160 mm, this is a robust solution for warehouses where reliability and consistent bay configuration are important.
Application in the warehouse
In practice, you use this beam to create or replace racking levels within Dexion P90 setups. The C35 connector ensures the correct coupling with frames with a material thickness of up to and including 2.5 mm, which helps maintain the correct fit and assembly. The material thickness of 2.0 mm contributes to a solid construction for daily pallet storage.
Practical for replacement or expansion
Ideal for B2B buyers who want to quickly expand or replace damaged beams without adjusting the entire system. Thanks to the Dexion coding on the beam, identification during maintenance and projects is easy, while the new condition and galvanized finish are suitable for long-term use in logistics environments.
Suitable for pallets
With a beam length of 3900 mm, this beam pair accommodates four euro pallets (800 x 1200 mm) or three block pallets (1000 x 1200 mm) side by side. In accordance with NEN-EN 15512, a minimum clearance of 75 mm between pallets is maintained, corresponding to an average maximum pallet width of 881.2 mm. This length is often chosen for racking bays with a fixed, uniform pallet layout.
| SKU | 100190043 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | Dexion |
| Artikelnummer Fabrikant | 100190043 |
| Product Group | Beam |
| Beam Type | P90 |
| Condition | New |
| Beam Length | 3900 |
| Height (mm) | 160 |
| Depth (mm) | 50 |
| Thickness (mm) | 2 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
