Dexion P90 Beam 2200x100x50x1.3 - C35 - galvanized
Dexion P90 galvanized beam 2200 mm
New Dexion P90 2C beam for pallet racking, galvanized and ideal as a replacement beam in warehouse fit-outs. Length 2200 mm, 100x50x1.3 with C35 connector; incl. 2 locking pins.
Specifications
- Brand/series: Dexion P90
- Type: 2C beam, galvanized (new)
- Size: 2200 x 100 x 50 mm
- Material thickness: 1.3 mm
- Connector: C35 (frames up to 2.5 mm)
- Included: 2 locking pins
- Suitable for: two block pallets (1000 x 1200 mm) side by side
Dexion P90 Beam 2300x100x50x1.3 - C35 - galvanized
Previous
Galvanized beam as a sturdy basis for reliable pallet racking
This new Dexion beam is designed for building a stable beam pair within P90 pallet racking. The galvanized finish helps protect against corrosion in intensive warehouse environments, making the beam suitable for durable use. With a length of 2200 mm and a profile of 100 x 50 mm, this component provides solid support for stored goods. Includes 2 locking pins for secure locking.
Application in the warehouse
A beam forms the load-bearing connection between two frames and determines the shelf-level layout of your racking. This version with C35 connector is intended for P90 frames and fits frames with a material thickness up to and including 2.5 mm, ensuring efficient assembly and alignment in existing racking bays.
Practical for replacement or expansion
Ideal for companies wanting to replace a damaged beam or expand a row of racking with original Dexion P90 components. The clear Dexion coding on the beam supports quick identification during maintenance and reorganization of your warehouse.
Suitable for pallets
With a beam length of 2200 mm, this beam pair accommodates two block pallets (1000 x 1200 mm) side by side. In accordance with NEN-EN 15512, a minimum clearance of 75 mm between pallets is maintained, corresponding to an average maximum pallet width of 987.5 mm. Alternatively, a combination of 1 euro pallet and 1 block pallet (two pallets in total) also fits. This size matches bays specifically set up for this type of pallet.
| SKU | 100174018 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | Dexion |
| Artikelnummer Fabrikant | 100174018 |
| Product Group | Beam |
| Beam Type | P90 |
| Condition | New |
| Beam Length | 2200 |
| Height (mm) | 100 |
| Depth (mm) | 50 |
| Thickness (mm) | 1.25 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
