Dexion P90 Beam 1800x100x50x1.3 - C35 - galvanized
Dexion P90 galvanized beam 1800 mm (C35)
New Dexion P90 2C beam for pallet racking, galvanized and ideal for replacement/expansion. Length 1800 mm, for a sturdy bay layout; incl. 2 locking pins, C35 connector for frames up to 2.5 mm.
Specifications
- Type: Dexion P90 beam (2C), galvanized
- Dim.: 1800 x 100 x 50 mm, 1.3 mm
- Connector: C35 (frames up to 2.5 mm)
- Includes: 2 locking pins
- Suitable for: two euro pallets (800 x 1200 mm) side by side
Dexion P90 Beam 2200x100x50x1.3 - C35 - galvanized
Previous
Galvanized beam as a robust basis for safe pallet storage
This Dexion beam for pallet racking is designed to form a stable and durable beam level within a P90 setup. The version is galvanized and supplied as a new component, including 2 locking pins for reliable locking. With a length of 1800 mm and a profile of 100 x 50 mm, this is a practical choice for warehouses that need sturdy support without unnecessary complexity.
Application in the warehouse
The beam connects two frames and directly contributes to the load-bearing structure of your racking. Thanks to the C35 connector type, it is intended for frames with a material thickness up to and including 2.5 mm, ensuring smooth and controlled assembly within the P90 product series. This is relevant for intensive use, varying pallet sizes, and narrow aisles where safety and dimensional accuracy matter.
Practical for replacement or expansion
Ideal for replacing damaged beams or expanding existing rows with identical components. The recognizable Dexion coding on the beam helps with quick identification and consistent maintenance of your pallet racking system.
Suitable for pallets
With a beam length of 1800 mm, this beam pair provides space for two euro pallets (800 x 1200 mm) side by side. In accordance with NEN-EN 15512, a minimum clearance of 75 mm between pallets is maintained, corresponding to an average maximum pallet width of 787.5 mm. This length is often chosen for racking bays with a fixed, uniform pallet layout.
| SKU | 100174010 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | Dexion |
| Artikelnummer Fabrikant | 100174010 |
| Product Group | Beam |
| Beam Type | P90 |
| Condition | New |
| Beam Length | 1800 |
| Height (mm) | 100 |
| Depth (mm) | 50 |
| Thickness (mm) | 1.25 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
