Mecalux beam 2C-S 1718 - 3300x170 mm
New Mecalux 2C-S beam 3300x170 mm
Robust Mecalux 2C-S 1718 pallet racking beam (3300x170x50 mm) with integrated locking pin for quick assembly and secure locking; ideal as a new replacement beam in warehouse fit-out.
Specifications Mecalux 2C-S beam
- Brand/type: Mecalux 2C-S 1718
- Dimensions: 3300x170x50 mm
- Locking: integrated locking pin
- Condition: new
- Suitable for: three europallets (800 x 1200 mm) or three block pallets (1000 x 1200 mm) side by side
Mecalux beam 2C-S 1615 - 3900x160 mm
Previous
Robust pallet racking component beam for safe and quick warehouse assembly
This new Mecalux 2C-S beam is intended for building up or repairing a pallet racking bay where reliability and ease of assembly matter. With a length of 3300 mm and a profile height of 170 mm, it forms the load-bearing connection between the uprights and supports the load of your storage levels. The integrated locking pin helps to lock the beam correctly right away, contributing to a stable setup in busy logistics environments.
Application in the warehouse
In pallet racking, the quality of the beams largely determines the safety and day-to-day use. This Mecalux 2C-S version (type 1718) is used in warehouse fit-outs where quick assembly and secure locking are desired, for example when extending racking bays or replacing a damaged component.
Practical for replacement or extension
For B2B buyers, this beam is a practical choice when specifically looking for a new component within the Mecalux 2C-S system. The dimensions of 3300x170x50 mm match common bay widths, making it easier to keep your pallet racking configuration consistent during maintenance, refurbishment or reorganisation.
Suitable for pallets
With a beam length of 3300 mm, this beam pair accommodates three europallets (800 x 1200 mm) or three block pallets (1000 x 1200 mm) side by side. In accordance with NEN-EN 15512, a minimum clearance of 75 mm between the pallets is maintained, corresponding to an average maximum pallet width of 1000 mm. Alternatively, a combination of 1 europallet and 2 block pallets (three pallets in total) also fits. This length is often chosen for racking bays with a fixed, uniform pallet layout.
| SKU | 2C-S1718-3300-N |
|---|---|
| Weight | 15.100000 |
| Verwachte levertijd | 4-6 weken |
| Country of Manufacture | Spain |
| Manufacturer | Mecalux |
| Artikelnummer Fabrikant | 1100201471 |
| Product Group | Beam |
| Beam Type | 2C-S |
| Condition | New |
| Beam Length | 3300 |
| Height (mm) | 170 |
| Depth (mm) | 50 |
| Thickness (mm) | 1.75 |
| Finish | Coated |
| Color | RAL 2001 |
| Delivery Time Indication | 3-5 weeks |
