Mecalux beam 2C-S 1615 - 3300x160 mm
New Mecalux 2C-S beam 3300x160x50 mm
Robust Mecalux 2C-S beam for pallet racking, ideal as a replacement beam for warehouse fit-outs; 3300 mm with integrated locking pin for quick installation and secure locking.
Specifications Mecalux beam
- Brand/type: Mecalux 2C-S 1615
- Dimension: 3300x160x50 mm
- Locking: integrated locking pin
- Condition: new
- Suitable for: three euro pallets (800 x 1200 mm) or three block pallets (1000 x 1200 mm) side by side
Mecalux beam 2C-S 1615 - 2850x160 mm
Previous
Robust pallet racking component beam for stable levels and secure locking
This Mecalux 2C-S beam is designed for pallet racking where reliability and quick installation matter. With a length of 3300 mm and a profile height of 160 mm, this beam forms a solid basis for creating or restoring a storage level. The integrated locking pin ensures direct, secure locking into the frame, contributing to stable racking construction in busy warehouse environments. This concerns a new beam.
Application in the warehouse
The beam is used to create racking bays at the desired height and transfers the load via the pallets to the uprights. Thanks to the integrated locking, the beam is suitable for situations with frequent loading and unloading and where extra security against unwanted detachment is important.
Practical for replacement or expansion
Ideal when you want to replace a damaged beam or expand an existing pallet racking with an extra level. The Mecalux 2C-S 1615 version with 3300x160x50 mm helps keep your warehouse fit-out efficiently operational with a suitable, professional racking component.
Suitable for pallets
With a beam length of 3300 mm, this beam pair accommodates three euro pallets (800 x 1200 mm) or three block pallets (1000 x 1200 mm) side by side. In accordance with NEN-EN 15512, a minimum clearance of 75 mm between pallets is maintained, corresponding to an average maximum pallet width of 1000 mm. Alternatively, a combination of 1 euro pallet and 2 block pallets (three pallets total) also fits. This size matches bays specifically set up for this type of pallet.
| SKU | 2C-S1615-3300-N |
|---|---|
| Weight | 15.100000 |
| Verwachte levertijd | 4-6 weken |
| Country of Manufacture | Spain |
| Manufacturer | Mecalux |
| Artikelnummer Fabrikant | 1100201468 |
| Product Group | Beam |
| Beam Type | 2C-S |
| Condition | New |
| Beam Length | 3300 |
| Height (mm) | 160 |
| Depth (mm) | 50 |
| Thickness (mm) | 1.5 |
| Finish | Coated |
| Color | RAL 2001 |
| Delivery Time Indication | 3-5 weeks |
