SSI-Schäfer Frame P73 - 3000 x 1050 mm - compleet
SSI Schäfer P73 complete frame 3000x1050 mm
Complete galvanized SSI Schäfer frame type P73 for pallet racking; ideal for replacement/expansion. New, with 2 uprights 75 mm and all bracing.
Specifications
- Type: P73 complete frame
- Brand: SSI Schäfer
- Dimensions: 3000 x 1050 mm
- 2 uprights 75 mm
- Galvanized + base plates
- Horizontal/diagonal bracing + fasteners
SSI-Schäfer Frame P73 - 3600 x 1050 mm - compleet
Previous
Complete frame for a stable foundation of your pallet racking
This complete SSI Schäfer frame from the P73 series forms the load-bearing side wall of a pallet racking system and is designed for safe, tight assembly of your storage solution. The frame is galvanized for reliable protection in warehouse environments and is supplied as a complete set with uprights, bracing and matching fastening material. With a height of 3000 mm and a frame depth of 1050 mm, this frame is suitable for standard pallet positions and a clear, professional racking layout.
Application in the warehouse
Frames determine the stability and alignment of your racking row. This SSI Schäfer P73 frame consists of two 75 mm wide uprights with horizontal and diagonal bracing, ensuring that the structure properly absorbs the load and forces in the system. The base plates provide a solid connection to the floor and support neat assembly.
Practical for replacement or expansion
Ideal when you want to restore an existing SSI Schäfer P73 installation after damage or when you want to expand your racking row with a frame that comes complete. With the supplied parts, you work efficiently, reduce assembly time and keep your pallet racking components consistent within one system.
Possible beam configurations and pallet heights
For a frame height of 3000 mm, the following beam configurations are possible (bay height and maximum pallet height per level, from bottom to top):
2 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1450 | 1300 | 1200 |
| 1st beam | 2900 | 1300 | 1200 |
3 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 1000 | 850 | 750 |
| 1st beam | 1950 | 800 | 700 |
| 2nd beam | 2900 | 800 | 700 |
4 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 750 | 600 | 500 |
| 1st beam | 1500 | 600 | 500 |
| 2nd beam | 2200 | 550 | 450 |
| 3rd beam | 2900 | 550 | 450 |
5 beams
| Level | Support height (mm) | Bay height (mm) | Max. pallet height (mm) |
|---|---|---|---|
| Ground level | 600 | 450 | 350 |
| 1st beam | 1200 | 450 | 350 |
| 2nd beam | 1800 | 450 | 350 |
| 3rd beam | 2350 | 400 | 300 |
| 4th beam | 2900 | 400 | 300 |
| SKU | RV1-773-0300-105 |
|---|---|
| Verwachte levertijd | 5-7 Weken |
| Country of Manufacture | Germany |
| Manufacturer | SSI Schäfer |
| Artikelnummer Fabrikant | RV1-773-0300-105 |
| Product Group | Complete Frames |
| Frame Type | P73 |
| Condition | New |
| Length (mm) | 3000 |
| Width (mm) | 75 |
| Depth (mm) | 1050 |
| Finish | Galvanized |
| Delivery Time Indication | 5-7 weeks |
